3 ph in and out variable frequency drives
VFD500-022G/030PT4B
Veikong 22kw 380V three phase in and out variable frequency inverters support different kind of practical functions and multiple communication methods.
Quantity
Veikong vfd 380V three phase in and out with multiple communication methods
VFD500-022G/030PT4B veikong vfd/ AC drive practical features for wide applications
Veikong vfd is an electronic device used to control the speed and torque of an AC (alternating current) motor by varying the frequency and voltage of the power supplied to it.
Veikong vfds are also known as Variable Frequency Drives (VFDs) and are commonly used in industrial and commercial applications for a wide range of motor-driven systems, including pumps, fans, conveyors, and more.
VFIs（Variable Frequency Inverter） use advanced control algorithms and power electronics to adjust the frequency and voltage of the power supplied to the motor, enabling precise control of motor speed and torque.
This leads to improved efficiency, reduced energy consumption, and lower operating costs.
An AC drive is another name for Veikong vfd.
An AC drive is another name for Veikong vfd.
It is an electronic device that adjusts the speed of an AC motor by varying the frequency and voltage of the power supplied to it.
AC drives are commonly used in industrial applications to control motors that drive various equipment, such as pumps, fans, conveyors, mixers, compressors, and more.
AC drives use advanced control algorithms and power electronics to provide optimal motor performance while reducing energy consumption and minimizing wear and tear on the motor.
AC drives are essential in modern motor control and help to improve system efficiency, reliability, and cost-effectiveness.
AC drive can make whoe whole production process more efficient
1. Veikong vfd support modbus RTU/RS485 built in
2. Veikong vfd support PC Tool Software
3. Veikong vfd support CANopen card optional
4. Veikong vfdr support profinet card optional
5. Veikong vfd support more compact to save space
6. Veikong vfd support independent dust design
7. Veikong vfd support IO exentsional card
8. Veikong vfd support multiple PG card
Veikong vfd/AC drive input and output specification for reference
| Item | AC drive Specification | |
| Function | Keypad | LED Digital keyboard and LCD keypad(option) |
| communication | Standard: MODBUS communication Option:Profibus-DP and CAN OPEN | |
| PG card | Incremental Encoder Interface Card (Differential Output and Open Collector), Rotary transformer Card | |
AC drive Input terminal | standard: 5 digital input terminals, one of which supports highspeed pulse input up to 50kHz; 2 analog input terminals, support 0 ~ 10V voltage input or 0 ~ 20mAcurrent input; Option card:4 digital input terminals 2 analog input terminals.support-10V-+10V voltage input | |
| Output terminal | standard: 1 digital output terminal; 1 high-speed pulse output terminal (open collector type), support 050kHz square wave signal output; 1 relay output terminal (relay 2 is an option ) 2 analog output terminals, support 0 ~ 20mA current output or 0 ~10V voltage output; Option card: 4 digital output terminals | |
Veikong vfd/AC drive R&D centre pics showing
What's the working principle of Veikong vfd or AC drive?
The working principle of Veikong vfd or AC drive is based on controlling the frequency and voltage of the power supplied to the AC motor. It involves the use of a rectifier, a DC bus, and an variable frequency inverter.
1. Rectifier: The rectifier converts AC power from the utility into DC power that is fed to the DC bus.
2. DC Bus: The DC bus is a capacitor bank that stores the DC power from the rectifier. It acts as a buffer and helps to smooth out any fluctuations in the DC voltage.
3. Inverter: The inverter converts the DC power from the DC bus into AC power that is supplied to the motor. The inverter uses pulse-width modulation (PWM) to adjust the frequency and voltage of the power supplied to the AC motor, enabling precise control of motor speed and torque.
The PWM technique used by the inverter involves generating a series of high-frequency pulses and varying their width to adjust the output voltage and frequency of the power supplied to the motor. The width of each pulse determines the amount of power flowing to the motor. By adjusting the pulse width and frequency, the VFI or AC drive can vary the speed and torque of the motor.
In summary, the VFI variable frequency inverter or AC drive works by rectifying the AC power into DC power, storing the DC power in a capacitor bank, and then using an inverter to generate pulse-width modulated AC power that is supplied to the AC motor. By controlling the frequency and voltage of the power supplied, the VFI or AC drive can precisely adjust the speed and torque of the motor.
1. Rectifier: The rectifier converts AC power from the utility into DC power that is fed to the DC bus.
2. DC Bus: The DC bus is a capacitor bank that stores the DC power from the rectifier. It acts as a buffer and helps to smooth out any fluctuations in the DC voltage.
3. Inverter: The inverter converts the DC power from the DC bus into AC power that is supplied to the motor. The inverter uses pulse-width modulation (PWM) to adjust the frequency and voltage of the power supplied to the AC motor, enabling precise control of motor speed and torque.
The PWM technique used by the inverter involves generating a series of high-frequency pulses and varying their width to adjust the output voltage and frequency of the power supplied to the motor. The width of each pulse determines the amount of power flowing to the motor. By adjusting the pulse width and frequency, the VFI or AC drive can vary the speed and torque of the motor.
In summary, the VFI variable frequency inverter or AC drive works by rectifying the AC power into DC power, storing the DC power in a capacitor bank, and then using an inverter to generate pulse-width modulated AC power that is supplied to the AC motor. By controlling the frequency and voltage of the power supplied, the VFI or AC drive can precisely adjust the speed and torque of the motor.
Veikong high performance variable frequency/ AC drive adopts the high quality components to ensure better working efficiency, especially in some strict applications, they do need AC drive can work very stable and efficiently, thus the whole industry would be better for them.
